MoneyGram® is a service for sending money anywhere in the world with a simple call at one of their kiosks. They have never ventured away from their very basic plastic or corrugate counter units. For a new push to rebrand the service, the client asked for a higher-end, exciting, new kiosk design. The result was a modular unit that could stand on its own or be modified to fit onto a counter (a first for the company)

Prototype of the counter-unit mode of the final concept. The wall on the right side was a must for privacy while using the service
Prototype of the standing-unit mode of the final concept, it was inspired by a red line traveling across a map (this photo of the display is missing the phone)
Prototype of the wall unit of the final concept
Full Size (highres_width x highres_height)
Branding and imagery for MoneyGram
Concept for an accompanying form holder for on store counters
Full Size (highres_width x highres_height)
The final concept for the form and information holder
Full Size (highres_width x highres_height)
An intital concept for a modular kiosk
Full Size (highres_width x highres_height)
Another intital concept for a modular kiosk, more focused on privacy
Full Size (highres_width x highres_height)
A revision of an initial concept, this one featured lights inside of the more private option
Full Size (highres_width x highres_height)
The initial concept that led to the final design
Full Size (highres_width x highres_height)
Another concept revision showing how the structure would hold up while in standing mode
A concept render for when the client requested the wall unit to take a design departure away from the standing and counter units
An early design concept featuring an embedded info lcd screen
An example of the engineering specs I made for the counter unit
