Edge Banding iron concept 1 - to apply adhesive backed edge banding wood to plywoods.
Flexible Hose kit with internal thread; hose retracts to reduce footprint and ease of storage. Each Port swivels to reduce hose kinking during use.
Flexible Hose kit with External thread; Each Port swivels to reduce hose kinking during use. Fixed hose length 2-1/4" can be stored on our Hose Reel which I also designed - shown below.
Exploration sketches page 1 for Rockler's brand, Dust Right handle products and accessories.
Exploration sketches page 2 for Rockler's brand, Dust Right handle products and accessories.
Rockler brand, Dust Right handle products and accessories.
Exploration sketches for the cam clamp, for T-track family of products.
Cam clamp for T-track family of products.
Exploration for ergonomic, overmolded Jig and Fence knobs for comfort and grip.
Ergonomic, overmolded Jig and Fence knobs for comfort and grip.
Dust Collection Power Cord problem. Following images are solutions with a new addition to the Dust Right collection.
Flat Packed Wire Organizer for Dust Collection accessories in the wood shop.
2-1/2" Hose Reel for upto 40' of dust collection hose. Key slots for left or right handed handle use/mounting to pull in hose slack.
Drill Press Dust Collection to have more fence adjustability/depth.
The Original Edge and Center marking gauge that's knocked off everywhere with the Rockler logo removed; Pencil Storage and Magnet for tool storage.
45° Corner Drilling jig for decorative box corner joints. 1/4, 3/8 & 1/2" drill guides. Markings for easy and quick setup based on material thickness.
Carbide Turning tool bit sharpener and magnetic for storage to sharpen Rockler replacement carbide bits.
Repeatable, quick setup Dado Router Jig. Utilizing your dado material, you can quickly setup the jig to create easily repeatable dado joints with a 1/4, 3/8 or 1/2 router bit with any standard full size router.
Quick easy setup with repeatable consistency Drawer pull jig that utilizes your drawer pull's size for more accurate drawer face drilling the first time. Fence has a stop to flip the fence for left/right drawer pulls; while also working as a bottom stop for vertical doors. Onboard storage for drill bit and allen wrench for fence stop.
Rockler branded Blum drawer slide installation drill jig. This drill the angle holes in the bottom of the drawer at the required spacing; as well as the end hold for the slides to attach to. Built in Drill bit depth finder, bits and allen wrenches for the drill bit stop collars.
T-track flex arm for shop use - holds up to 3" diameter for dust, lights, dust boot, cables or dust hose.
2x4 pipe clamp clamps; pipe clamps can flip down out of the way for panels, or be utilized sideways to hold doors for edge planing purposes, etc.
Radius gauges, Blue set includes 1/16 -15/16" diameters; with spring loaded stop indicator for reference; Black set includes 1/8"-1" diameters also with spring loaded arrow indicator. Both sets have convex and concave sizes.
Adjustable, Flexible Sanding - key lock center with soft grip handle for quick setup / changing out of sanding grits on hand carvings or complex turnings that require hand sanding.
gLike
Tool Design
Selected Work - Project & Design Lead projects. Uploads of completed/launched products.
