Achilles 88 is a developing product from Achilles tyre for passenger car. Achilles 88 is specially designed for your maximum comfortable ride. Its excellent construction makes you feel
perfectly secure.

I designed the sidewall design. The concept is simple; balance & move. Because Achilles 88 is a symmetric directional tyre, I decide to make the sidewall can seen in both side movement rotation (to right or to left).

I make 3 alternative design concept, and the final design was chosen on design No. 3 with several change.

It has 3 features product:
> FOUR GROOVES; Maximizing power of maneuvering
>ZIGZAG GROOVES ON
SHOULDER BLOCKS; Improving contact performance.
Excellent grip ability, good braking
performance, and extended mileage,
while lowering heating, wear ability
and fuel economy benefits.
> OPTIMIZED CENTER BLOCK
ARRANGEMENT;
Variable-pitch angle on center
blocks provide good road contact
for increased ride-comfort.

3D modelling has made by R&D engineering team of Multistrada

View Website
Achilles 88 Sidewall design concept No.1
Achilles 88 Sidewall design concept No.2
Achilles 88 Sidewall design concept No.3
Achilles 88 Sidewall; Final Design Concept. Develop by alternative No. 3 (Perspective right view)
Achilles 88 Sidewall; Final Design Concept. Develop by alternative No. 3 (Right view)
Achilles 88 Sidewall; Final Design Concept. Develop by alternative No. 3 (Perspective top side view)
Feature of Achilles 88: FOUR GROOVES; Maximizing power of maneuvering
Feature of Achilles 88: ZIGZAG GROOVES ON SHOULDER BLOCKS; Improving contact performance. Excellent grip ability, good braking performance, and extended mileage, while lowering heating, wear ability and fuel economy benefits
Feature of Achilles 88: OPTIMIZED CENTER BLOCK ARRANGEMENT; Variable-pitch angle on center blocks provide good road contact for increased ride-comfort
